The user connects and sets the protection relay to detect line and earth currents.

Provision to vary the length parametersĪ fault application switch and earth fault resistors allow studies of earth fault currents and the operation of relays of varying sensitivity.įor protection tests, current transformers (CTs) in the test circuits connect to the protection relay fitted to the control panel.

Operating under variable balanced or unbalanced RLC (resistive, inductive and capacitive) loads.The three-phase transmission line is in six sections represented in ‘per-unit’ values. monitor the voltage, current and power at any point along the line.set up ‘Pi’ or ‘Tee’ methods of loss profiling using different values of capacitance and.change the length of the simulated line.The single-phase transmission line includes a set of inductive impedances connected in series. The effects can be monitored by instruments at the send and receive ends of the transmission lines. The lines may be loaded by the resistive, capacitive and inductive loads included.

The upper panel has a single-phase transmission line equivalent circuit, and the lower panel a three-phase transmission line. The console is divided into two control panels, each with detailed mimic diagrams. The configurable simulated transmission lines allow realistic studies of short, medium and long-distance transmission lines under variable load and power factor conditions, as well as with inserted faults.

The Transmission Line Simulator investigates single-phase and three-phase transmission lines.
